1000 Data Memory Ultrasonic Velocity Meter Ultrasonic Thickness Measurement Equipment
Ask Latest Price
Video Channel
Brand Name :HUATEC
Model Number :TG-1000
Certification :ISO, CE, GOST
Place of Origin :Beijing
MOQ :1pcs
Payment Terms :T/T, Paypal, Western Union
Supply Ability :500pcs per month
Delivery Time :1-4days
Packaging Details :Standard export package
Model :TG-1000
Display :FSTN LCD Display with backlight
Power supply :3.7V Li-Ion chargeable battery
Measuring Range :0.50mm to 508mm(0.02" to 20.00")
Size :157mm*78mm*37mm
Weight :250g
Probe calibration :Real-time Temperature Compensation Technic supporting One-time probe calibration for long term usage
Gain :16 stages gain adjustable
Memory :1000 datas
Sould velocity :1 ~ 19999 m/s
more
Contact Now

Add to Cart
Find Similar Videos
Ultrasonic Paint Thickness Gauge Ultrasonic Thickness Gauge Echo-Echo.Wall Thickness Gauge 00:18
Ultrasonic Paint Thickness Gauge Ultrasonic Thickness Gauge Echo-Echo.Wall Thickness Gauge
TG-8812D Ut Thickness Meter Penetration Coating Mode 2.5-25mm Through 2mm Coating 00:57
TG-8812D Ut Thickness Meter Penetration Coating Mode 2.5-25mm Through 2mm Coating
0.75-300mm NDT Equipment Ultrasonic Wall Plastic Metal Thickness Measuring Machine 00:27
0.75-300mm NDT Equipment Ultrasonic Wall Plastic Metal Thickness Measuring Machine
400mm Bluetooth Ultrasonic Wall Thickness Gauge For metal glass and Plastic 01:21
400mm Bluetooth Ultrasonic Wall Thickness Gauge For metal glass and Plastic
A-Scan Snapshot Ultrasonic Plastic Film Wall Thickness Gauge 00:28
A-Scan Snapshot Ultrasonic Plastic Film Wall Thickness Gauge
Through Coating Ultrasonic Wall Thickness Gauge Ultrasonic Metal Thickness Gauge 00:26
Through Coating Ultrasonic Wall Thickness Gauge Ultrasonic Metal Thickness Gauge
High Precision Steel Thickness Measuring Device CE Certified RoHS Certification 00:28
High Precision Steel Thickness Measuring Device CE Certified RoHS Certification
High Temperature Electromagnetic Non Contact Thickness Gauge Meter No Coupling Agent 02:28
High Temperature Electromagnetic Non Contact Thickness Gauge Meter No Coupling Agent
AA Battery Portable Hardness Tester Cylindrical Spherical Outside And Inside Surface Metal Durometer 02:49
AA Battery Portable Hardness Tester Cylindrical Spherical Outside And Inside Surface Metal Durometer
Porosity Detector Inspecting Instrument Holiday Tester Embedding Pipe Outer Antisepsis Status 02:14
Porosity Detector Inspecting Instrument Holiday Tester Embedding Pipe Outer Antisepsis Status
View Product Description

Portable Ultrasonic Velocity Gauge Ultrasonic Thickness Measurement Equipment Spheroidization rate tester

TG-1000 is a portable ultrasonic velocity gauge,Spheroidization rate tester. Based on the same operating principles as SONAR it is capable of measuring the speed of sound (velocity) through the material. It is suitable for a variety of metallic and non-metallic materials such as casts, alloys or plastics, and can be used to indicate the consistency of the material.

Features:

  • High precision timing chip & V-Path model used for precision measurement
  • Real-time Temperature Compensation Technic supporting One-time probe calibration for long term usage.
  • Velocity can be directly measured and used in evaluation of spheroidization rate
  • Bluetooth & Mini-USB interface for printing & communication, host software upgradable

Main Functions:

  • Scan mode, min/max capture mode, and alarm mode support
  • Thickness can be measured by a known velocity
  • 16 stages gain adjustable
  • Storage capacity of 1000 measurements with velocity, thickness, time, etc.
  • Communicate with PC or smart phones

  • Technical Parameters
Sound Velocity Range 1 ~ 19999 m/s Thickness Range See Probe Parameters
Resolution 1m/s, 0.001mm / 0.0001inches Accuracy See Probe Parameters
Measuring Period 4 times per second Probe Frequency 2MHz,3MHz,5MHz,7.5MHz
Calibration Mode Probe Calibration, Real-time Temperature Compensation Data Storage 1000 measurements, including thickness, sound velocity, time, etc.
Calibration block 4.000mm(Steel) Gain Adjustable 16 Stages
Measuring Mode scan, min/max capture, alarm Thickness measure Support
Display English
FSTN LCD Display with backlight		 Display Content Thickness, Sound velocity, Stability, Battery, Measuring Mode, Time, etc.
Communication Bluetooth & Mini-USB interface, virtual serial port protocol Print Optional portable Bluetooth thermal printers
Power Supply 3.7V Li-Ion chargeable battery Power off Timeout power off, low battery power off
Usage Temperature -10 ~ 50 °C Storage Temperature -30 ~ 60 °C
Size 157mm*78mm*37mm Weight About 260g
Shell Material ABS & PC alloy Box Material ABS (IK08 / IP67)

Probe parameters

Label 5M Φ10 5M PT-08 7.5M PT-06 2M ZT-12 3M GT-12
Measure Range (Steel) 0.75~300 mm 0.8~225 mm 0.8~50 mm 3.0~400 mm 2.0~200 mm
Min. Measure Diameter Ø25 x 3 mm Ø20 x 1.2 mm Ø15 x 1.2 mm Ø30 x 4 mm Ø25 x 3 mm
Probe Diameter 13mm 11mm 9mm 17mm 15mm
Probe Frequency 5MHz 5MHz 7.5MHz 2MHz 3MHz
Contact Temperature -10~60°C -10~60°C -10~60°C -10~60°C -10~310°C

Version Comparison

Version Online measurement Command control
TG-1000 x x
TG-1000C √ √
